3D Solution

Overview

넥시아디바이스는 세계 최고 수준의 2D to 3D Real-time image Conversion용 칩 솔루션을 보유하고 있습니다.
2D-to-3D Real-time image Conversion 기술은 일반적인 2D 영상을 실시간 생동감있는 3D 입체영상으로 변환하여 시청할 수 있는 첨단의 3D 컨텐츠 생성 기술입니다.QVGA급의
저해상도 2D 영상부터 4K 고해상도 이르는 다양한 해상도의 2D 영상을 실시간으로 3D 입체변환할 수 있으며, 동영상/ 정지영상 등 다양한 종류의 영상에 대해 적용할 수 있습니다.

Product

2D to 3D Realtime Converting SoC (model No : NX7000 L/R)

Key Feature

- 2D-to-3D Real-Time Natrual Image Conversion
- Full HD(1,920*1,080pixel) Video Converter
- Embedded 3D Formatter (3 Type)
- LVDS or RGB I/F

지원제품

3D TV, 3D PC용 모니터, 디지털카메라, PMP, 노트북, 넷북, 노트패드, 전자액자, 스마트 폰, 휴대폰, 전자사전,
네비게이션, DMB 플레이어, DVD/Blu-ray 플레이어, 디지털카매라, 디지털캠코더, 빔프로젝터 등

Spec

2D-to-3D Real-Time Image Conversion
- Input Image
  - Max 24Bit Raw RGB format
  - Up to 1,920x1,080pixel@60Hz
- Output Image
  - Up to 1,920x1,080pixel@60Hz

3D Effect Control
- Depth Control : 0 ~ 255 level
- 3D Parallax Control : 0 ~ 255 level

Reverse(Left, Right Image) Selection
3D-to-2D mode change

2D-to-2D & 3D-to-3D Bypass
- Support 3D Parallax Control during 3D-to-3D bypass mode

3D Formatter
- Side-by-Side (Half resolution)
- Line-by-Line
- Vertical Stripe(or Pixel by Pixel)

Host Interface
- Standard I2C slave Interface
- Selectable chip ID(by selection PIN/1Bit) : { 1_0101_PIN }
- Support 8bit address with Read & Write flag
- Support 8bit & 16bit Read and Write Mode

Dual Channel LVDS(Rx/Tx) Interface
- Operating Frequency : Max. 85MHz
- External 1.8V Power Supply
- Transmit Data Format : VESA/JEIDA

Package Specification
- Package
  - NX7000R : 6mm x 6mm/121Ball/FBGA
  - NX7000L : 6mm x 6mm/95Ball/FBGA
- Operation Voltage : 1.8V(both Core & I/O)
- · Power Consumption : 26mA(Active mode),
  6mA(2D Bypass mode),
  0.8mA(Sleep mode)
- ※ RGB I/F, Full-HD Image, 1.8V 기준

2D to 3D Realtime Converting IP

Key Feature

2D-to-3D Real-Time Natural Image Conversion
Support UHD(3,840*2,160pixel) Resolution
Embedded 3D Formatter (3 Type)

Feature

2D-to-3D Real-Time Image Conversion
- Input Image
  - Max 36Bit Raw RGB format
  - Up to 3,840x2,160pixel@60Hz
- Output Image
  - Up to 3,840x2,160pixel@60Hz
3D Effect Control
- Depth Control : 0 ~ 255 level
- 3D Parallax Control : 0 ~ 255 level
Reverse(Left, Right Image) Selection
3D-to-2D mode change
2D-to-2D & 3D-to-3D Bypass
- Support 3D Parallax Control during 3D-to-3D bypass mode
3D Formatter
- Side-by-Side
- Line-by-Line
- Vertical Stripe(or Pixel by Pixel)
